Description
Large Storage. Small Footprint. Sleek Design.
The first and largest of our Ultra Series bulk tanks, this classy and robust unit is the perfect solution for large fleets and retailers.
Aboveground bulk tanks offer many advantages including lower initial cost and ease of expansion.
However, where to locate the tank at your facility can be an issue. KleerBlue’s Ultra Series turn-key unit solves this dilemma.
Offering the industry’s largest storage capacity within a compact, heated and insulated, and aesthetically pleasing unit, it is everything you’ve ever wanted in an aboveground bulk tank.
Features- Size that Eliminates Timing Issues
- Take control of your bulk delivery schedule and ensure you’re getting the best price for your fluid
- 2,600 or 4,400 gallon capacities allow for improved scheduling and pricing
- Extra-large 8,800 gallon capacity allows for 5000+ gallon transport deliveries without needing to completely empty the tank
- Take control of your bulk delivery schedule and ensure you’re getting the best price for your fluid
- Quality that brings peace of mind
- Made for the most demanding environments
- Volume safety margins combined with overfill protection prevents inventory loss
- Secondary containment - 2 inner tanks and an outer wall
- Weather-proof exterior offers long life and low maintenance
- Made for the most demanding environments
- Design that Looks great at your Facility
- Large bulk storage doesn’t have to be an eyesore.
- The white weather-proof exterior can be customized to match your overall facility branding and design.
- The small footprint offers many placement options.
- Aboveground tank eliminates need to bury an underground storage tank.
- Large bulk storage doesn’t have to be an eyesore.
- Built for all Weather Conditions
- Industrial-grade insulation protects against both extreme heat and cold.
- Highly Efficient Tank Heating System
Inventory
Displaying prices & availability for Ohio, United States in CAD. Change location.
Models matching criteria: 3
Ultra Series Bulk Storage Units view more
- Capacity: 2600 Gallon Ultra
- Dimensions: 102” Width x 150” Length x 122” Height
Ultra Series Bulk Storage Units view more
- Capacity: 4400 Gallon Ultra
- Dimensions: 130” Width x 178” Length x 122” Height
Ultra Series Bulk Storage Units view more
- Capacity: 8800 Gallon Ultra Enclosure
- Dimensions: 130” Width x 266” Length x 122” Height
Specifications
Specifications
Brand
Standards & Approvals
- ISO 22241 - 3 & 4
Operating Temperature
- -22°F/-30°C to 130°F/54°C
Size & Dimensions
- Capacity: 8,800 gallon maximum (8,000 gallons usable capacity)
- Capacity: 6,400 gallon maximum (5,760 gallons usable capacity)
- Capacity: 2,600 Gallons / 4,400 Gallons
- Capacity: 1,000 Gallons
- Dimensions: 130” width x 266” length x 122” height
- Dimensions: 112” width x 258” length x 120” height
- Dimensions: 102” width x 145” length x 119” height
- Dimensions: 130” width x 178” length x 119” height
- Dimensions: 102” width x 150” length x 122” height
Tank & Container
- HDPE primary tank and secondary containment
- High-performance composite galvanized steel external container
- Steel floor panels with all-steel sub-floor
- Top mount and side access doors
- Patent Pending Design
- Easy-to-clean FRP interior surfaces
- Powder-coated steel base frame
- Inside enclosure light
Heating & Insulation
- R-14 Insulation
- Option: Thermostatically controlled KleerBlue immersion heating system
- Option: Exhaust fan
- Forced air heating system
- R-5 Insulated top & sides
Electronics
- Three 20 amp 115V AC circuits required
- External digital level display
- UL-508A pump and dispenser control box
- Option: Multiple dispenser switch box
- Option: External junction box
- (1) 115v 20 amp and (1) 115v 30 amp AC circuits required
Pump
- Submersible pump activated by up to 4 dispensers
- Option: 1 HP DEF submersible pump
- Option: Dual or Tri DEF submersible pumps
- ¾ HP DEF submersible pump
Security/Accident Prevention
- Lockable access door
- Electric overfill protection
- Pressure relief system
- Vent with protective screen
- Option: Audible overfill alarm
- Option: 1” Stainless Steel filter for discharge line
- Mechanical overfill protection
Fill Inlets
- 2” Stainless Steel lockable ball valve
- Option: 2” Stainless Steel drybreak (Parker, OPW or TODO)
Dispenser Compatibilities
- Female NPT stainless steel pump discharge line connection
- Compatible with KleerBlue and 3rd party dispensers
- Dispenser switch box for remote dispensing (see electronics)
- Option: Powder coated transition boxes for 3rd party dispensing options
Installation
- Forklift compatible
- Completely assembled and wired
- Anchor Mount Tabs
