6334A 2-Wire Programmable Transmitter

Brand: PR Electronics
Request a Quote
  • TC input
  • High measurement accuracy
  • Galvanic isolation
  • Programmable sensor error value
  • 1- or 2-channel version
Features
  • Within a few seconds the user can program PR6334A to measure temperatures within all TC ranges defined by the norms.
  • Cold junction compensation (CJC) with a built-in temperature sensor.
  • A limit can be programmed on the output signal.
  • Continuous check of vital stored data for safety reasons.
show more
  • TC input
  • High measurement accuracy
  • Galvanic isolation
  • Programmable sensor error value
  • 1- or 2-channel version
Features
  • Within a few seconds the user can program PR6334A to measure temperatures within all TC ranges defined by the norms.
  • Cold junction compensation (CJC) with a built-in temperature sensor.
  • A limit can be programmed on the output signal.
  • Continuous check of vital stored data for safety reasons.
Close
Close

Specifications

Brand

Ambient Temperature Range

  • -40° to 85° C (-40° to 185° F)

Approvals & Certifications

  • ATEX 2014/34/EU KEMA 10-ATEX-0005 X
  • EAC TR CU 020/2011
  • IECEx dEK 14.0047 X

Environmental Protection

  • IP20

Humidity

  • < 95 % Relative Humidity, Non-Condensing

Output

  • 4-20 mA Signal Range

Response Time

  • 1 to 60 seconds Programmable

Supply Voltage

  • 7.2-35 Vdc
Close

Applications

  • Linearized temperature measurement with TC sensor.
  • Amplification of bipolar mV signals to a 4...20 mA signal, optionally linearized according to a defined linearization function.
