Description
The DPG200A is a high accuracy intelligent digital pressure gauge with built-in high-precision pressure sensor that accurately displays pressure in real time and features high precision and long-term stability.
This digital pressure gauge is equipped with a large-size LCD liquid crystal display with 5-bit display. It has various functions such as clearing, backlighting, power on/off, unit switching, low voltage alarm, peak recording, pressure percentage display etc.
It is easy to operate and easy to install. The product adopts 304 stainless steel shell and joint, which has good shock resistance and can measure gas, liquid, oil and other non-corrosive medium for stainless steel.
The DPG200A digital pressure gauge is powered by 3pcs AA batteries, and can also be powered by USB. The DPG200A intelligent digital pressure gauge is suitable for pressure measurement in portable pressure measurement, equipment matching, calibration equipment, etc
Features- 304 stainless steel matte casing, dial diameter 100 mm
- With pressure scale bar indicating the current pressure percentage
- 5-digit display with high resolution
- Accuracy level 0.4% F.S
- 3 pcs AA battery power supply, can last for 18-24 months
- Maximum and minimum record function
- Pressure unit switching (Mpa, kpa, pa, psi, bar, kgf/cm2, mbar, inH2O, mmHg, Torr, ATM, mmH2O)
- One-button clear zero
- USB power supply, battery dual power supply
- Strong media compatibility, can measure water, oil, gas and other media that are non-corrosive to stainless steel
Specifications
Specifications
Brand
Pressure Type
- Gauge Pressure
- Absolute Pressure
- Negative Gauge Pressure
Overload
- < 10 MPa 150 %, ≥ 10 MPa 120 %
Accuracy Rating
- 0.4 % Full Scale
Long-Termstability
- 0.2 % Full Scale / Year
Supply Voltage
- USB Powered
- 4.5 V (3 pcs AA Batteries)
Battery Life
- ≥ 18 Months (Subject to Specific Operating Conditions)
Sampling Frequency
- 3 Times/Second
Display Screen
- 5-Digital LCD Display
Backlight Color
- White
Measuring Medium
- Etc.
- Oil
- Water
- Air
Electromagnetic Compatibility
- Anti-Electromagnetic Interference Design, in Accordance with EN 61326
Data Memory
- Permanent EEPROM
Peak Record
- Yes
Case Material
- 304 Stainless Steel
Interface Material
- 304 Stainless Steel
Product Features
- Backlight
- Power ON/OFF
Range (Vacuum)
- (0~-100) kPa
- 0 to 100 kPa
- 0 to 250 kPa
- 0 to 400 kPa
- 0-0.1 MPa
Range (Compound)
- (-50~50) kPa
- (-25~25) kPa
- (-10~10) kPa
- (-5~5) kPa
- (-2.5~2.5) kPa
- (-0.1 to 2.5) MPa
- (-0.1 to 1.0) MPa
- (-0.1 to 0.6) MPa
- (-0.1 to 0.4) MPa
- (-0.1 to 0.25) MPa
- (-0.1 to 0.1) MPa
Range (Micro Pressure)
- (0 to 100) kPa
- (0 to 50) kPa
- (0 to 25) kPa
- (0 to 10) kPa
- (0 to 5) kPa
- (0 to 2) kPa
Range (Conventional)
- (0~60) MPa
- (0 to 1.6) MPa
- (0 to 1) MPa
- (0~600) kPa
- (0 to 400) kPa
- (0 to 250) kPa
- (0 to 160) kPa
Range (High Pressure)
- (0~100) MPa
- (0 to 160) MPa
Applications
Applications
- Water Treatment System
- Water Pump and Air Compressor
- Mechanical and Electrical Equipment Automation
- Construction Machinery
- Medical Equipment
- Hydraulic and Pneumatic Systems
- Laboratory
- Test Stand
